Arcadyan Telstra 5G Home Modem X55 AW1000 Openwrt WiFi 6 AX3600 Gigabit Ethernet Port 5G CPE Easy Mesh WiFi Router

Telstra AW1000 5G modem. The modem is mains-powered, has a clean matte , and is a bit tall and chunky. In terms of functionality, you get the standard inclusions: four Ethernet LAN ports, one WAN port, a full-size USB port, dual-band WiFi, and even supports WiFi 6.
The AW1000 5G Modem acts more as a consistent home connection, rather than the hotspot nature of the 5G Wi-Fi Pro. It comes in a relatively tall and boxy frame, giving that modem feel that typical broadband networks tend to have.
The Telstra 5G Home Modem is designed to make ting up a 5G Home Internet connection as easy as possible. All it needs is power, plus placement in the part of your home that receives the strongest Telstra 5G signal.
The modem relies on an easy-to-understand, light-based system for an indication of how strong the 5G signal is. There's also a 2.5GB WAN/LAN port, four gigabit Ethernet ports, and a WPS push button for straightforward WiFi connectivity with compatible devices.
For faster local network speeds, the Telstra 5G Home Modem has inbuilt WiFi 6, which means it won't be a bottleneck when connecting WiFi 6 devices to the speedy potential of 5G internet. It's a dual-band router, too, meaning you can take of the faster 5GHz local WiFi band and the longer-range 2.4GHz band, too.
:
IPQ8072A
1G RAM+1G ROM
QCN5024+QCN5054, AX3600
Interface: 2.5G * 1+1G * 4, RJ11 * 1, and 1 USB 3.0 port, antenna interface * 2
The internal module is RG500Q-EA ( x55)
Product Model
Telstra 5G Home Modem AW1000
LED Light
Wi-Fi, WPS, RE
Interfaces
1 x LAN/WAN Port
4 x LAN Gigabit Ethernet Port
1 x Phone Port
1 x USB 3.0 Port
1 x Sim Card Slot
2 x Antennas Port
Frequency Band
5G NR NSA
n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78/n79 n2/n5/n7/n12/n25/n41/n48/n66/n71/n77/n78
5G NR SA
n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78/n79 n2/n5/n7/n12/n25/n41/n48/n66/n71/n77/n78
LTE-FDD
B1/B3/B5/B7/B8/B18/B19/B20/B26/B28/B32/B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B29/B30/B66/B71
LTE-TDD
B34/B38/39/B40/B41/B42/B43 B41/B42/B43/B48
WCDMA
B1/B3/B5/B6/B8/B19 B2/B4/B5
Wi-Fi Standards
EasyMesh
802.11 a/b/g/n/ac/ax, Wi-Fi 6 AX3600Mbps
2.4GHz & 5GHz
Security
Protected Management Frames
WPA™-Personal
WP™-Personal
WPA3™-Personal
